Inner Sleeve
- Flexible and expandable innermost core. (1 mm)
- Contains Dyneema® that offers maximum strength with minimum weight.
- Dyneema® doesn’t fray and is up to 40% stronger than aramid fibers such as Kevlar®.
- Prevents slipping of the sleeve on the mandrel.
- Extremely durable and resistant to moisture, UV light and chemicals.
Foam Layer
- 1 mm – Compressible pre-compressed Foam Layer.
- The compressible pre-compressed Foam Layer has high rebound resilience and is up to 50% compressible without bulging.
- Resistant to permanent deformation, good abrasion resistance, resistance to aging, weathering and cleaning solvents used for polymer plate cleaning.
Tech Core Material
- Stitch, Bonded and Compressed Tech Core Material in various thicknesses.
- Contains a filament fiber base which is volumized by feiberglass infused with Epoxy Vinyl-Ester-Resin.
- Light weight with extreme high flexural strength and form stability.
Outer Surface Layer
- The 2.5 mm. Outer surface layer contains Epoxy Vinyl-Ester-Resin reinforced with technical filaments and polyester fleece.
- High chemical and temperature resistance.
Outer Compressible Surface Layer
- The compressible surface layer (40, 50 or 60 ShA) consists of cellular, water crossed-linked foamed polyurethane (water/isocyanate reaction).
- It is produced in densities from 300 – 650 kg/m3.
- The layer can be compressed by up to 80% of its original height with limited bulging and very minimal permanent set.
- Further outstanding properties of the compressible layer are:
- High rebound resilience
- Large volume compressibility
- High resistance to permanent deformation, also with dynamic loads
- Good abrasion resistance
- Resistance to aging and weathering
Features and Options
Sealed Edges
Protects the core from damage by ink and solvents
Axial line
Makes mounting easier
Inner metal Ring incl. Registration Slot
Most strong and durable slot solution
Versions
Possible optionsPlate Sleeves
Tech®
Tech Pro®
Tech Pro+®
1 x zero line axial
Yes
Yes
Yes
Sealed ends on both sides
No
Yes
Yes
Inner metal ring incl. registration slot
No
No
Yes
Tech®
- 1 x zero line axial
Tech Pro®
- 1 x zero line axial
- Sealed ends on both sides
Tech Pro+®
- 1 x zero line axial
- Sealed ends on both sides
- Inner metal ring incl. registration slot
